East Texas DX club

Start of the etdx station.

Anticipate 4 permanent operating positions with easy setup for 6 operating positions.

Building planned for 40ft x 50ft and 18ft walls to eve.

Anticipate having a 120 foot Rohn 55 next to shack

At 70 feet on tower 20 Meter Mosley CL-204 fixed direction NE to catch US East Coast and Europe

Planned - 2 - Tennadyne Log Periodic on top of tower.

Planned to feed Tennadyne Log in shack will have triplexer and band pass filters on Log Periodic for multiple stations to use 10m, 15m, 20m at same time

Currently have Low Band Systems - Quadplexer 40m, 20m, 15m, 10m, with band pass filters rated for 500w each.

Currently have GAP Challenger

Additional informationWeight21 lbsDimensions104 × 10 × 3 inBands80m, 40m, 20m, 15m, 12m, 10m, 6m, 2mBandwidth -- Under 2:1Entire band on 40m, 20m, 15m, 12m, 10m, 6m, 2m, 80m over 130 KHz, 10m over 1MHzHeight31.5 ftWeight18 lbsRadiation EfficiencyExceed conventional verticals by up to 600%MountGround or elevated. A ground mount is supplied.Counterpoise3 at 25 ftGround Area RequiredFits in 10 ft by 12 ft area
